The H-2-FX CONTROLAIR Valve is a lever operated, 3-way, pressure regulating valve. Air pressure is increased, decreased or maintained at the OUT port according to lever position. Facing the lever side of the valve, clockwise lever movement increases pressure, (see diagram.) When the lever remains in one position, the CONTROLAIR Valve maintains outlet pressure for that position.
For throttle control applications, the valve is set with a pre-load of 10 psi and has a 10-60 psi delivery pressure range.
